Example, X‑CUT™ SP33G

The C stands for Chisel. The chain has square corner cutters, which provides superior cutting efficiency. This cutter profile is only recommended for professional users working in clean conditions. (Figure A)

The S stands for Semi-Chisel. The corners are rounded, which eases maintenance and have good stay-sharp properties. This cutter profile is more forgiving regarding filing angles and is less sensitive to dirt. Suitable for all users. (Figure B)

Example, X‑CUT™ SP33G

P – Pixel
Some of our chains have a P in their name, and the P stands for Pixel. Pixel chain and guide bars, with thinner chassis, are low in weight and provide a narrow cut – resulting in enhanced cutting efficiency. This chain type is only to be used with pixel guide bars. (Figure A)

No letter – Standard
However, it is more common that there is no letter after the C or S in the chain name. That chain type is a tougher, broader cutting chain, with standard chassis enabling more rigid and robust chains and bars. (Figure B)

Example, X‑CUT™ SP33G

The first digit after the letters tells the pitch size. Mini chains have low profile cutters, smaller drive links and are suitable for smaller chain saws.

1 = 1/4” mini
2 = .325” mini
3 = .325”
8 = 3/8
9 = 3/8” mini

The pitch of the chain must match the pitch of the guide bar and the drive sprocket on your chainsaw.
